Cordial CSE 0,5 NN 7A PUR

The Cordial CSE 0.5 NN 7A PUR data patch cable is constructed with CCAT 7A PUR bulk cable and HIROSE RJ45 connectors, equipped with Neutrik etherCON connector protection. This combination is designed for professional applications where a reliable and stable data connection is required. Thanks to double S/FTP shielding, the cable supports CAT 7A data signals with a bandwidth of up to 1000 MHz (Gigabit Ethernet). The PUR outer jacket protects the cable from external influences and mechanical stress, making it suitable for mobile use, both indoors and outdoors.

This cable is specifically designed for audio networks (e.g. Dante), lighting control and EtherSound systems. The flexible inner conductor with AWG 26/7 makes the cable very suitable for patch connections and direct connections to equipment. Even with frequent winding and unwinding, the cable remains comfortable to use.

The CSE NN 7A PUR supports Power over Ethernet according to IEEE 802.3af-2003 with up to 15.4 watts of power. This makes the cable usable in a variety of network and AV installations. High abrasion resistance and resistance to oil, microbes and chemicals ensure reliable operation in demanding environments such as stage use, mobile installations and outdoor applications.

Cordial CSE 0.5 NN 7A PUR features:

• length 50 cm
• flexible, robust and easy to coil
• PUR jacket for mobile indoor and outdoor use
• CAT 7A data class up to 1000 MHz
• full S/FTP shielding
• AWG 26/7 with 7 cores per conductor
• Power over Ethernet up to 15.4 watts according to IEEE 802.3af-2003, maximum channel length 70 m
• flame retardant according to UL 1581 §1090, §1100 (FT2) and IEC 60332-1-2
• halogen-free according to EN 50267-2-1 and IEC 60754-1
• oil-resistant according to IEC 60811-2-1, ICEA S-82-552 and ASTM IRM 902
• sludge-proof according to NEK 606
• ozone-resistant according to EN 50396
• microbe resistant according to VDE 0282/10
• chemically resistant to, among others, diesel, kerosene and petroleum
• HIROSE RJ45 connectors with NEUTRIK etherCON connector protection
• transparent shrink tubing for easy cable identification

Cordial CSE 0.5 NN 7A PUR specifications:

• conductor area 0.14 mm²
• AWG 26/7
• conductor structure 7 x 0.14 mm²
• sheath material PUR
• insulation foam-skin PE, nominal 1,05 mm
• shielding S/FTP
• outer jacket PUR
• application data and ethernet
• outside diameter 6.4 mm ± 0.2 mm
• weight of bulk cable approx. 46 kg per km
• nominal conductor capacity < 44 pF/m
• conductor resistance 140 Ω per km
• PoE up to 15.4 watts according to IEEE 802.3af-2003, max. channel length 70 m
• maximum channel-link Class FA / CAT 7A (1000 MHz) 77 m
• maximum permanent-link Class FA / CAT 7A (1000 MHz) 65 m
• cable type CCAT 7A PUR, sheathing PUR
• core assignment RJ45 pinout T568B
• connector brand NEUTRIK / HIROSE, 2x Neutrik NE 8 MX-B-1 + HIROSE RJ45 TM31
