Cordial CSE 5 NH 5e PUR
CAT 5e data patch cable up to 100 MHz
length: 5 mtr.
1x Hirose RJ45 and 1x Hirose RJ45 with Neutrik etherCON protection
PUR jacket for mobile use indoors and outdoors
high flexibility with small bending radius
Power over Ethernet up to 15.4 watts
- Buy 2 for €57.82 each and save 2%
- Buy 3 for €57.23 each and save 3%
- Buy 4 for €56.64 each and save 4%
- Buy 5 for €56.05 each and save 5%
- Buy 6 for €55.46 each and save 6%
- Buy 7 for €54.87 each and save 7%
- Buy 8 for €54.28 each and save 8%
- Buy 9 for €53.69 each and save 9%
- Buy 10 for €53.10 each and save 10%
Want to know when this item is back in stock? Send us your email address and we'll notify you as soon as it's available!
Our product experts are happy to help you!
Cordial CSE 5 NH 5e PUR data patch cable is constructed with CCAT 5e PUR bulk cable and Hirose RJ45 connectors, with one side featuring Neutrik etherCON connector protection. This cable features a flexible AWG 26/19 inner conductor and a special TPE-V stabilizer, making it very suitable for audio networking (Dante), lighting control and EtherSound systems.
The cable combines high flexibility with a small bending radius and is easily coiled. This makes it ideal as a patch cable, for device connections and for mobile use. Even in stage applications and outdoor transmissions, the cable continues to function reliably. The PUR jacket protects against mechanical stress and external influences. In addition, this cable supports Power over Ethernet according to IEEE 802.3af-2003 with up to 15.4 watts of power.
Cordial CSE 5 NH 5e PUR features:
- length: 5 meters
- very flexible, robust and easy to roll up
- PUR jacket for mobile indoor and outdoor use
- CAT 5e data class up to 100 MHz
- S/UTP shielding
- AWG 26/19 with 19 cores per conductor
- Power over Ethernet up to 15.4 watts according to IEEE 802.3af-2003, maximum channel length 67 m
- HIROSE RJ45 connectors with NEUTRIK etherCON connector protection
- transparent shrink tubing for easy cable identification
- Bulk cable: type CCAT 5e PUR
- core assignment RJ45 pinout T568B
- connectors: 1x Hirose RJ45 TM31 + 1x Neutrik NE 8 MX-B-1 + HiroseRJ45 TM31
Cordial CSE 5 NH 5e PUR specifications:
- cable type: CAT 5e S/UTP
- conductor surface: 0,15 mm²
- AWG 26/19
- construction conductor 19 x 0,15 mm²
- pUR sheath material
- conductor insulation solid PE, nominal 1,03 mm
- shielding S/UTP
- outer jacket: PUR
- application data and ethernet
- outside diameter 6.5 mm ± 0.2 mm
- weight of bulk cable approx. 56 kg per km
- nominal conductor capacity < 50 pF/m
- conductor resistance 140 Ω per km
- PoE up to 15.4 watts according to IEEE 802.3af-2003, max. channel length 67 m
- maximum channel-link Class D / CAT 5e (100 MHz) 73 m
- maximum permanent-link Class D / CAT 5e (100 MHz) 61 m
| Brand | Cordial |
|---|---|
| Ean Code | 4250197664325 |
| Article number | 75917 |
