LD Systems MAUI 28 G3 MIX

Compact, powerful and easy to use - a PA with column remains the perfect companion for DJs and smaller bands. The LD Systems MAUI Series represents this all-in-one concept in every detail, offering an unparalleled PA package in terms of sound, design, technology and operation. Set up, plug in and go!

This is especially true of the MAUI G3 MIX versions, which have integrated 6-channel digital mixers. All components are integrated and perfectly matched: mixer, effects, dynamics processing, DSP controller, power amplifiers and speakers. Wireless remote control via a free MAUI app (available on iOS or Android smartphones and tablets) is also included.

The MAUI 28 G3 MIX delivers huge, powerful and precise sound with 1,030 W RMS power (2,060 W peak). It is suitable for a variety of applications, for example as a main PA for singer-songwriters and small bands, a sound system for mobile DJs and formations, or a public address system at weddings, corporate events and more.

[[READMORE]]

Mix

The built-in 6-channel mixer adapts to user preferences through Easy and Expert Modes. Users can choose between intuitive 3-band EQs or more advanced 5-way fully parametric control. An expanded effects section offers the full range of reverb, delay and dynamics processing options. Users can control all mixer and effect settings wirelessly via the app.

For stereo applications, two MAUI 28 G3 MIX units can be linked via SysLink®. In this setting, twice the number of mixer channels can be used.

Beautiful, but loud, but beautiful

With its slim and elegant design, the MAUI 28 G3 MIX looks particularly attractive. The two aluminum column elements sit on the front of the subwoofer, adding to the seamless visual impression. The columns are equipped with 12 x 3.5'' midrange drivers and 2 x 1'' tweeters, which ensure even sound distribution with constant horizontal dispersion in combination with the innovative phase plug design. In addition, the BEM-optimized waveguide - in front of the tweeters - carries the high frequencies to the back of the room.

LD Systems engineers also took great care with the crossover filter between the midrange and tweeter speakers. The goal was to reduce harmonic distortion and interference to make the sound even more transparent, lively and powerful. The result speaks for itself: highly accurate reproduction of vocals and instruments across the entire 120° x 30° dispersion field. The MAUI 28 G3 MIX columns are designed as cardioid speakers. This ensures controlled low mids at the front and up to 18 dB attenuation at the rear, resulting in a pure stage sound.

All about the bass

Equipped with a single 12'' woofer and four bass reflex ports, the MAUI 28 G3 MIX subwoofer delivers a clear, tight and punchy low to 37 Hz. By using a second subwoofer, bass response can be increased by up to 6 dB and the subwoofer can be controlled in a cardioid configuration (Cardioid preset) at the touch of a button. In addition, the subwoofer's ultra-durable polyurea coating withstands the harshest conditions on the road.

A true sound machine, the MAUI 28 G3 MIX will impress solo artists, singer/songwriters or small bands on a daily basis with its smart features. Transport is as easy as ever, while the hidden multi-pin connections between the elements provide more stability during assembly. There's nothing that can knock the MAUI off its feet so easily....

Specifications:

• Color: Black
• Max. SPL (peak): 127 dB
• Frequency range (-10dB): 37 Hz - 20000 Hz
• Dispersion (H x V): 120° x 30 °
• Overall height: 2052 mm
• Weight: 36.2 kg
• Features: 6-channel mixer, App Control (Easy + Expert Mode), Bluetooth Audio Streaming, Cardioid column, Footswitch input, Built-in effects + dynamics, SysLink® (cascading of 2 systems)

Subwoofer:

• Dimensions woofer: 12 "
• Woofer dimensions (mm): 305 mm
• Woofer magnet: Ferrite
• Woofer brand: Custom-made
• Woofer voice coil (inch): 3 "
• Woofer voice coil (mm): 76.2 mm
• Cabinet construction: Bass Reflex
• Housing material: 15 mm birch plywood
• Enclosure Surface: Polyurea
• Subwoofer dimensions (W x H x D): 370 x 527 x 472 mm
• Subwoofer weight: 23.6 kg

Mid/Hi System

• Voice coil dimensions: 12 x 3.5 "
• Voice coil dimensions (mm): 12 x 89 mm
• Voice coil magnet: Ferrite
• Voice coil brand: Custom made
• Voice coil for voice coil: 0.75 "
• Voice coil for voice coil: 19 mm
• Tweeter size: 2 x 1 "
• Tweeter dimensions (mm): 2 x 25.4 mm
• Tweeter Magnet: Neodymium
• Tweeter brand: Custom-made
• Tweeter voice coil: 1"
• Tweeter voice coil (mm): 25.4 mm
• Waveguide: CD waveguide
• Speaker inputs: 1
• Cabinet material mid/hi system: Aluminum
• Mid/Hi system cabinet surface: Powder-coated
• Mid/Hi system width: 103 mm
• Mid/Hi system height: 1540 mm
• Mid/Hi system depth: 135 mm
• Weight mid/hi system: 12.6 kg

Amplifier

• Amplifier: Class D
• System output power (RMS): 1030 W
• System Output (Peak): 2060 W
• Protection circuitry: DC protection, Multi-band limiter, Short circuit, Thermal protection
• Cooling: Convection
• Controls: Bluetooth button HOLD ON LINK, Channel level, Input type, Main level, Page button, On/Off, Remote control, Rotary/push encoder
• Indicators: Bluetooth, Channel level, Display, Input type, Limit, Mute, Power, Protect (protection circuit enabled), Remote control, Signal
• Mains connection: PowerCon
• Operating voltage: 100 V AC - 120 V AC, 50 - 60 Hz, 220 V AC - 240 V AC, 50-60 Hz
• Fuse: T5AL / 250 V
• Power consumption: 400 W
• Ambient temperature (operating): 0 - 40 °C
• Relative humidity: < 80% (non-condensing)
• Line inputs: 4, Footswitch
• Line Input Connections: Combo XLR / TRS
• Line outputs: 1 System OUT, 2 Monitor OUT
• Line outputs: XLR male
• Number of speaker outputs: 1
• Speaker outputs: Customized
• Other connections: 1 RJ45 SysLink® port
• Bluetooth standard: A2DP
• Bluetooth version: 4.2
• Bluetooth Audio Decoder: SBC
