Whether you're a presenter, singer-songwriter, or in a band; the Yamaha StagePas 600BT is the all-in-one PA solution for great sound in small to mid-sized venues. The StagePas 600BT offers extensive features and connections. Equipped with Bluetooth wireless audio connectivity, the 600BT can stream audio to your StagePas system from any Bluetooth-connected device such as a smartphone, tablet or laptop up to 20 meters away. The StagePas 600BT offers 3-band EQ on each channel. Four mic/line inputs have XLR jacks, with phantom power on channels 1-2 and 1/4" XLR combo inputs on channels 3-4; channel 4 is switchable to hi-Z for instruments with passive pickups. There are also three stereo line input channels that are switchable to mono use, plus support for RCA and 1/8" stereo mini inputs. Monitor and subwoofer outputs on the 600BT make expansion easy. For shows that require a monitor mix or extended low, simply connect powered speakers, such as Yamaha's DXR Series full-range speakers or DXS Series subwoofers.
Bluetooth connectivity for setup flexibility
At Klundert Music, we find the Bluetooth connectivity of the StagePas 600BT useful for easy playback of backing tracks, loops or, e.g., pause music, without a cable. Audio is routed to channels 9/10 on the StagePas 600BT's mixer. Couldn't be simpler!
Lightweight and portable
The StagePas 600BT includes two lightweight speakers and a detachable powered mixer, a pair of speaker cables and a power cord. The mixer fits into one of the speaker enclosures, making it easy to transport and taking up less space during use.
Excellent sound quality without the hassle
Advanced Yamaha technology helps the StagePas achieve outstanding professional sound quality without the hassle. Built-in feedback suppression addresses problem frequencies before they become audible. With one-button controls, Yamaha Master EQ optimizes the sound for the environment. Channels 1 through 4 feature independent sends for the four types of studio reverb (Hall, Plate, Room and Echo), which are derived from Yamaha's acclaimed SPX series of effects processors. You can also turn reverb on and off via an optional footswitch: handy when you want to take a moment to talk without reverb, between vocal numbers.
Intelligent power management
With the StagePas 600BT delivering as much as 680 watts of power, you're sure to be heard clearly in small to medium-sized venues. Intelligent DSP and advanced limiting protect the system and ensure the most efficient power consumption.
- compact PA system with Bluetooth functionality
- consisting of two speakers with built-in components and storage compartments
- lightweight speaker system
Mixer: - 10 channels (6x mono, 2x stereo)
- analog inputs: 6x mono mic/line with 4x mono or 2x stereo
- Bluetooth functionality
- channel EQ: 3-band with 8kHz HIGH shelving, 2.5 kHz MID peaking and 100 Hz LOW shelving
- Hi-Z switch on channel 4
- stereo/mono switch on channel 5/6 and 9/10
- digital effects through SPX digital reverb module, with 4 reverb types and parameter control
- output processing through feedback suppressor and 1-button Master EQ
- phantom power supply: +30V on channel 1 and 2
- L+R speaker output through 6.35mm jack
- monitor output via 6.35mm jack (L/MONO + R)
- subwoofer output via 6.35mm jack (MONO) with automatic HPF for the 600i speakers
- footswitch connection via 6.35mm jack plug for reverb activation
- dimensions mixer: 348 x 197 x 135 mm
- mixer weight: 3.8 kg
Amplifier and speakers: - 10 inch woofer and 1.4 inch tweeter
- maximum SPL: 129 dB SPL per speaker
- frequency range: 55 to 20,000 Hz
- two-way bass reflex speakers
- beam angle: 90 x 60 degrees
- floor monitor angle: 50 degrees
- 1 top handle per speaker
- 34.8 - 35.2 mm tripod adapter with StageLok locking mechanism
- amplifier module power maximum: 600W (300 + 300W)
- amplifier module power continuous: 560W (280 + 280W)
- power consumption: 35W in standby mode, 100W at 1/8 power consumption
- speaker dimensions: 335 x 545 x 319 mm
- weight of speakers: 10.8 kg
Connections: - channel 1/2: XLR, microphone or line
- channel 3/4: XLR, mic or line; 6.35mm jack, mic or line
- channel 5/6: 6.35mm jack
- channel 7/8: 6.35mm jack or RCA
- channel 9/10: 6.35mm jack, 3.5mm jack or iPod/iPhone USB
Included accessories: cover panel, power cable (2 meters), 2x speaker cable (6 meters each) and 12x non-slip pads
