Tascam ML-16D

The Tascam ML-16D sends 16 audio channels in and out of a Dante audio network with up to 24-bit/96kHz resolution. In addition, this device supports AES67, allowing you to connect to Ravenna and other compatible networks as well. For maximum reliability, the ML-16D is equipped with dual, redundant Ethernet connections. The reference level is adjustable, and the LED display gives you an instant view of signal levels.

Using Audinate's Dante Controller software, you can flexibly manage audio routing via your Mac or PC. Ideal for institutions looking to add a multitrack audio link to their existing IP network.

[[READMORE]]

Digital audio easily via Dante with the Tascam ML-16D
The Tascam ML-16D is a 16-channel converter from analog to Dante. With Dante (Digital Audio Network Through Ethernet), you send uncompressed, multichannel digital audio over a standard Ethernet connection, with extremely low latency. In practice, this means you no longer need a jumble of analog cables. A single Cat 5e or Cat 6 cable is all you need. You can use existing network infrastructure of a studio, theater or venue, without additional cabling. The physical location of your devices does not matter - as long as they are connected to the same Ethernet network. You easily control the patching and routing of signals between Dante devices via the Dante Controller software.

Tascam ML-16D features:

• 16-channel analog-to-Dante converter with 16-in/16-out analog I/O via 4 D-sub connections
• supports AES67 for interfacing to Ravenna and other compatible networks
• supports up to 24-bit/96kHz resolution for high sound quality
• dual, redundant Ethernet connections for maximum operational reliability
• adjustable reference level metering
• LED display for instant visibility of your signal levels
• flexible routing via Audinate's Dante Controller on Mac or PC
• suitable for stadiums, theaters, concert halls, opera houses, churches, universities, etc.
• 19 inch: 1U
• dimensions: 483 x 45 x 304 mm
• weight: 3.3 kg
