Yamaha DXL1K
Column PA system, active
Active column PA system
Easy to carry and set up
Make yourself heard wherever you are
Four-band parametric EQ
Built-in tweeters and mixer
- Buy 2 for €945.70 each and save 2%
- Buy 3 for €936.05 each and save 3%
- Buy 4 for €926.40 each and save 4%
- Buy 5 for €916.75 each and save 5%
- Buy 6 for €907.10 each and save 6%
- Buy 7 for €897.45 each and save 7%
- Buy 8 for €887.80 each and save 8%
- Buy 9 for €878.15 each and save 9%
- Buy 10 for €868.50 each and save 10%
Want to know when this item is back in stock? Send us your email address and we'll notify you as soon as it's available!
Our product experts are happy to help you!
The Yamaha DXL1K is a portable PA column system and perfect for professionals! The DXL1K consists of a 12-inch subwoofer section and a column with ten 1.5-inch tweeters for the mids and treble. This column delivers the same full, rounded sound as the new Stagepas 1K MK2. Quick and easy to set up, this column system is the ideal complement to the Stagepas 1K MK2 for complete stereo playback. This speaker can also be used as a freestanding PA system with the sound quality and amplification of the Stagepas.
For the DXL1K, Yamaha also used the same Class D amplifier, rated at 1100 watts, for maximum sound reproduction. This provides a loud, room-filling sound of 125 dB. For transporting and protecting the column system, the DXL1K comes with a matching case with compartments for accessories.
You control the additional four-band parametric EQ from the STAGEPAS Controller app. You also have a built-in two-channel mixer for adjusting and mixing inputs. Add punch to your sounds with main output compression with speech, music and DJ modes.
- Low frequency driver: 12" subwoofer
- Speaker array: 10 x 1.5" drivers
- Amplification: Class D
- Output power: 1100 W (LF: 500 W, HF: 600 W)
- Sound power level: 125 dB SPL
- Coverage: 170° H x 30° V
- Built-in mixer: 2 channels
- Effects: Main Compressor
- Dimensions (W x H x D): 334 x 2000 x 418 mm
- Weight: 23 kg (total), 20 kg (sub only)
| Brand | Yamaha |
|---|---|
| Ean Code | 4957812680103 |
| Woofer (inch) | 12" |
| Power (Watt, RMS) | 1000 - 1249 Watt |
| Tweeter (inch) | 1,5" |
| Analog XLR input | yes |
| Analog jack input | yes |
| Analog RCA input | no |
| Digital input | not applicable |
| Enclosure | plastic |
| Can be used as a monitor | yes |
| Bluetooth audio | yes |
| Direct out | yes |
| Sound pressure in dB (SPL) | 120 - 129 dB |
| Passive connection | jack |
| Rechargable | no |
| Article number | 69977 |
| Size (packaging) | 33,4 cm x 200 cm x 41,8 cm |
