Yamaha DZR10

The Yamaha DZR10 is an active speaker and offers superior clarity and best-in-class SPL performance. This 2-way bi-amped PA speaker features a powerful 2000W Class D amplifier, wide frequency range and can truly handle any application.

Advanced DSP processing ensures high-resolution sound with super-low latency, while optimized presets and an intuitive LCD screen make choosing your settings a breeze. The DZR10 fits into any configuration and can also function as a stage monitor. The DZR10 has a lightweight but durable plywood enclosure with a high-quality polyurea coating.

Advanced DSP Processing
Our Klundert Engineers are impressed with the DZR10's smart DSP processing. Yamaha's Advanced FIR-X tuning uses a combination of FIR filtering and corrective EQ to minimize phase distortion, ensuring smooth frequency response, stunning clarity and accurate sound reproduction. D-Contour is an intelligent multi-band compressor that maintains ultimate clarity even when you drive the DZR10 to its highest output level. D-Contour has two settings, FOH/MAIN and MONITOR mode, so you can tailor the DZR10's sound to any application. You also get DSP limiters that protect both the power supply, power amplifiers and transducers from damage. Despite all this powerful DSP, the DZR10 remains user-friendly, thanks to optimized factory settings and an intuitive LCD screen.

Custom speakers
The Yamaha DZR10 features great-sounding, custom-designed speakers. The HF (high frequency) transducer includes a 2-inch voice coil and 1-inch compression driver, a titanium diaphragm and neodymium magnet in a heat-resistant aluminum frame. The LF (low frequency) transducer uses a large 3-inch voice coil, cast aluminum frame and a powerful but lightweight neodymium magnet to handle the DZR10's bass. The DZR10 is not all about power, however. Its low-end response is tightly controlled, especially in the mid-bass and vocal range.

Smart, ultraflexible design
The DZR10 fits into any configuration, thanks to its ultraflexible design. Its rotatable horn allows vertical or horizontal mounting. The speaker has a 90x60° dispersion from a vertical position. Thanks to the DZR10's constant-direction horn, you get smooth, flat coverage - its innovative design minimizes the roll-off that conventional horns often cause.

Powerful Class D amplifier
The DZR-10 is loaded with 2 kW of Class D power. It delivers an impressive sound pressure level of 137 dB SPL. Enjoy maximum power along with stable, worry-free operation, thanks to a universal switching power supply. Moreover, this amplifier is optimized for the DZR10's transducers, ensuring top sound quality.

Yamaha DZR10 features:

• 2-way active speaker with 2" HF and 10" LF drivers

• features a powerful 2,000 watt Class D amplifier and wide frequency range (44Hz - 20kHz)

• advanced FIR-X tuning uses a combination of FIR filtering and corrective EQ to minimize phase distortion

• D-Contour is an intelligent multiband compressor that maintains clarity at high output levels

• FOH/MAIN and MONITOR modes allow you to fine-tune your sound to your application

• DSP protection protects the power supply, power amplifiers and transducers from damage.

• optimized factory settings and an intuitive LCD screen make operation easy

• great-sounding, custom-made transducers (speakers)

• rotatable horn for vertical or horizontal mounting

• 90x60° dispersion from a vertical position

• constant-directional horn delivers even coverage with no roll-off

• lightweight but durable plywood housing with a high-quality polyurea coating

Yamaha DZR10 specifications:

• active two-way fullrange speaker
• DSP processor with presets
• wide frequency range from 44 to 20,000 Hz

• maximum sound pressure level of 137 dB (SPL)
• can be tilted as a monitor

• 35 millimeter stand recess

• multifunctional housing

• dimensions: 537 x 345 x 315 mm

• weight: 17.9 kg
