Powerful, passive 12" speaker. Can also be used as a monitor due to the clever cabinet design (50° wedge angle). The sound quality is amazing! Of course with speaker flange at the bottom for placement on a stand.
The 12' speaker gives a somewhat louder / nicer low-mid due to the 12" LF driver instead of a 10" (as with the CBR10).
Passive 12" speaker
For stage use
Cabinet: plastic
Metal grill
Sturdy side handles
35 mm stand adapter for intermediate pole or stand
Woofer: 12 inch
Compression driver: 1.4 inch voice coil
Frequency response (-10 dB): 48 Hz - 20 kHz
Maximum SPL: 125 dB
Sensitivity: 96 dB SPL
Radiation angle vertical: 60 degrees
Horizontal radiation angle: 90 degrees
Built-in crossover, crossover frequency 2.1 kHz
Load capacity: 350 Watt continuous and 700 Watt peak
Impedance: 8 Ohm
Inputs: 1x Neutrik SpeakOn NL4MP and 1x 6.35 mm jack
Floor monitor angle: 50 degrees
Dimensions: 376 x 601 x 348 mm
Weight: 13.9 kg
Brand
Yamaha
Ean Code
4957812574549
Woofer grootte
12"
RMS power in Watt
250 - 499 Watt
Tweeter size
1"
Analogue XLR input
no
Analogue jack aansluiting
no
Analogue RCA input
no
Digital input
not applicable
Speaker enclosure
plastic
To be used as a monitor
yes
Bluetooth audio
no
Direct out
yes
Sound pressure in dB SPL
120 - 129 dB
Passive connection
speakon
Rechargable
no
Article number
58162
Size (packaging)
70 cm x 48 cm x 46 cm
