Shure SLXD4D+E=-G65

The Shure SLXD4D+E=-G65 is a digital, two-channel receiver in half-rack format designed for use with SLX-D+ transmitters. This receiver combines the familiar 24-bit audio quality and stable RF performance of SLX-D+ with added flexibility thanks to two independent receiver channels in one compact housing. Ideal for fixed installations, rentals, stages and presentation applications where you want to reliably deploy multiple wireless microphones.

You can combine this receiver with the (handheld) transmitters from the SLXD+ series.

Thanks to the wide tuning range of 136 MHz and the ShowLink® Ease control link, receiver and transmitters stay in sync with each other automatically. Interference is actively monitored, and in the event of interference, the system can automatically deploy a new, free frequency without audible interruption. Via Wireless Workbench and the mobile app, you keep complete oversight, locally or remotely.

[[READMORE]]

What's new in SLX-D+ (vs. SLX-D)?

• 136 MHz wide tuning range for greater deployment by region, supporting up to 14 simultaneous systems within 8 MHz TV bands
• ShowLink® Ease: adjust transmitter parameters remotely from the receiver, including:
• change transmitter frequency as soon as a free frequency is found
• adjust transmitter gain
• lock/unlock transmitter controls
• easily update transmitter firmware
• automatically find and relay a new frequency to receiver and transmitter in case of interference
• Shure Digital Feedback Reduction automatically reduces unwanted feedback
• AES-256 encryption standard on every SLX-D+ component for secure transmission

What hasn't changed?

• same 24-bit digital audio, stable RF performance and Shure reliability
• monitoring and control via Wireless Workbench® and the WWB Mobile app (iOS/Android)
• choice of rack-ready and portable configurations and microphone options
• optional Shure lithium-ion batteries and chargers with real-time runtime information
• backwards compatible: SLX-D+ components also work with existing SLX-D components

Shure SLXD4D+E=-G65 features:

• digital 2-channel half-rack receiver for SLX-D+ transmitters
• frequency band G65: 470 - 606 MHz
• 24-bit/48 kHz audio conversion with >118 dB dynamic range
• 136 MHz tuning range for flexible frequency management
• ShowLink® Ease control link for remote transmitter settings and automatic frequency switching
• Shure Digital Feedback Reduction against feedback
• AES-256 encryption for secure wireless audio
• Audio Summing function for internal mixing of both channels
• mic/line switching with 30 dB pad
• monitoring and control via Wireless Workbench and WWB Mobile app (Wi-Fi and Bluetooth)
• network port (Ethernet) for integration and system management

In the box

• Shure SLXD4D+ dual channel receiver
• 2x 1/4-wave antenna
• 2x bulkhead adapter
• 2x 55.88 cm (22 in.) BNC cable
• 19 inch rackmount kit
• power supply

Shure SLXD4D+E=-G65 specifications:

• dimensions (h x w x d): 42 x 197 x 152 m
• weight: 930 g (without antennas)
• power supply: 15 VDC @ 360 mA (external power supply, tip positive)
• RF input, BNC, impedance: 50 Ohm
• audio output: gain range: -18 to +42 dB (1 dB steps)
• outputs: 6.35 mm TRS (balanced), XLR (balanced)
• mic/line switch: 30 dB pad
• phantom power protection: yes (6.35 mm and XLR)
• Network, interface: single port Ethernet 10/100 Mbps
• addressing: DHCP or manual IP
