Shure SLXD4+E=-G65

The Shure SLXD4+E=-G65 is a digital, single-channel, half-rack format receiver designed for use with SLX-D+ transmitters. You get clear 24-bit audio, stable RF performance and smart control features that allow you to switch quickly as the environment changes. Thanks to the ShowLink® Ease control link, receiver and transmitter stay in sync, and you can adjust important transmitter settings remotely through the paired receiver.

You can combine this receiver with the SLXD+ series (handheld) transmitters.

In practice, the SLXD+ series is a strong choice for e.g. installations, rentals, venues, churches and presentation rooms where you just have to work wirelessly: automatic scanning, automatic adjustment in case of interference and overview via Wireless Workbench and the mobile app.

[[READMORE]]

Shure SLXD4+E=-G65 features:

• digital 1-channel half-rack receiver for SLX-D+ transmitters
• frequency band G65: 470 - 606 MHz
• 24-bit/48 kHz audio conversion with >118 dB dynamic range
• ShowLink® Ease control link for remote transmitter settings and automatic frequency change in the event of interference
• Shure Digital Feedback Reduction against feedback
• AES-256 encryption for secure wireless audio
• mic/line switchable with 30 dB pad
• monitoring and control via Wireless Workbench and WWB Mobile app (Wi-Fi/Bluetooth)
• network port (Ethernet) for integration and management

What's new in SLX-D+ (vs. SLX-D)?

• 136 MHz wide tuning range for greater deployment by region, supporting up to 14 simultaneous systems within 8 MHz TV bands
• ShowLink® Ease: adjust transmitter parameters remotely from the receiver, including:
• change transmitter frequency as soon as a free frequency is found
• adjust transmitter gain
• lock/unlock transmitter controls
• easily update transmitter firmware
• automatically find and relay a new frequency to receiver and transmitter in case of interference
• Shure Digital Feedback Reduction automatically reduces unwanted feedback
• AES-256 encryption standard on every SLX-D+ component for secure transmission

What hasn't changed?

• same 24-bit digital audio, stable RF performance and Shure reliability
• monitoring and control via Wireless Workbench® and the WWB Mobile app (iOS/Android)
• choice of rack-ready and portable configurations and microphone options
• optional Shure lithium-ion batteries and chargers with real-time runtime information
• backwards compatible: SLX-D+ components also work with existing SLX-D components

In the box:

• Shure SLXD4+ single channel receiver
• 2x 1/4-wave antenna
• 2x bulkhead adapter
• 2x 55.88 cm (22 inch) BNC cable
• 19 inch rackmount kit
• power supply

Shure SLXD4+E=-G65 specifications:

• dimensions (h x w x d): 42 x 197 x 152 mm
• weight: 900 g (without antennas)
• power supply: 15 VDC @ 360 mA (external power supply, tip positive)
• RF input, BNC, impedance: 50 ohms
• Audio output: gain range: -18 to +42 dB (1 dB steps)
• outputs: 6.35 mm TRS (balanced), XLR (balanced)
• mic/line switch: 30 dB pad
• phantom power protection: yes (6.35 mm and XLR)
• network: interface: single port Ethernet 10/100 Mbps
• addressing: DHCP or manual
